Vacuum Pump RT 75 We offer a wide range of Vacuum Pump RT 75.
|
Pumping Speed
|
1250 l/min
|
|
Ultimate Pressure
|
Gas Ballast Closed
|
5X10-4 torr ( 6.7 X 10-2 Pa )
|
|
Gas Ballast Open
|
5X10-2 torr ( 6.7 Pa )
|
|
Power Input
|
Standard
|
220VAC/380VAC 3Ø 50/60 Hz
|
|
Customer's Request (Voltage, Frequency and Phase)
|
|
Full Load Power
|
3.7 kW (5 HP)
|
|
Motor Speed
|
1700 rpm
|
|
Inlet and Outlet
|
Standard
|
NW40
|
|
Option I
|
NW25 or Hose (Ø36 OD)
|
|
Option II
|
User requested type
|
|
Oil Capacity
|
6200 cc ( 6.2l )
|
|
Weight
|
110 kg
|
|
Overall Dimension (mm)
|
226(W) X 624(L) X 346(H)
|
|
